Pneumatikus szerszámok

FS10C

FY10C

FS26

FY8A

FZ45C

FS48C

IDLE SPEED:

• from 500 to 20.000 r.p.m.

DRILLING CAPACITY:

• from 1 to 10 mm Ø

TYPE OF DRILL:

• A = with self-locking chuck
• C = with keyed chuck
•    = without chuck

STARTING SYSTEM:

• lever

APPLICATION FIELD:

• they are mainly used in vertical drilling operations on any kind of material

FY8PA

FDE49PC

FO20P

FSE17PA

FSE26PC

IDLE SPEED:

• from 170 to 20.000 r.p.m.

DRILLING CAPACITY:

• from 1 to 13 mm Ø

TYPE OF DRILL:

• A = with self-locking chuck
• C = with keyed chuck
•    = without chuck

STARTING SYSTEM:

• push button

APPLICATION FIELD:

• they are suitable for a lot of drilling operations on every type of material and in every industrial field.
• FO series is particularly effective for heavy-duty drilling and boring operations in which the drill needs to be moved forward with considerable force.

FS65/90C

FY8/90C

FS17/90P

FS48/90P

FZ31/30P

FZ31/90P

FS17/90C

IDLE SPEED:

• from 500 to 4.500 r.p.m.

DRILLING CAPACITY:

• from 1 to 10 mm Ø

TYPE OF DRILL:

• A = with self-locking chuck
• C = with keyed chuck
•    = without chuck

Models with 30° (FZ series) and 90° angle heads 90° angle drills (FS series) are also available in the version which permits the use of collet instead of the normal keyed chuck

STARTING SYSTEM:

• lever

APPLICATION FIELD:

• they are necessary when one needs to drill in tight spaces where access is difficult, such as up against walls, close to metal sections and profiles beams
